【DK-DEV-10CX220-A】Cyclone 10 GX FPGA Development Kit

  • 产品型号: DK-DEV-10CX220-A/C10GFP(Part No:T0556)
  • 产品品牌: TERASIC友晶科技/Intel FPGA
  • 产品规格: Cyclone 10 GX FPGAs
  • 产品价格: 欢迎咨询采购,量多优惠多,提供完善的售后保障和支持!
  • 咨询热线:18062095810

If you are evaluating Intel® Cyclone® 10 GX FPGAs or already at the design concept stage, Intel has a complete ecosystem to support your design, which includes development kits, software, intellectual property (IP), design examples , Design Solutions Network partners , and Engineer-to-Engineer videos to reduce your time to market.

The Intel Cyclone 10 GX FPGA Development Kit is an ideal starting point for applications, such as embedded vision , factory automation , or video connectivity evaluation or concept proving.

With this development kit, you can:

  • Develop designs for Intel Cyclone 10 GX FPGAs
  • Develop and test PCI Express* (PCIe*) 2.0 designs using the PCI-SIG*- compliant development board
  • Direct connection via USB 3.1 Type C, small form-factor pluggable (SFP+), and RJ-45 connectors
  • Develop modular and scalable designs by using direct connection or via the FPGA mezzanine card (FMC) connector to support protocols, such as USB 3.1 Gen2, GigE Vision,12G serial digital interface (SDI) , DisplayPort , HDMI , JESD204B , Serial Rapid I/O*, Common Public Radio Interface (CPRI), and IEEE 1588

For a complete list of IP cores from both Intel and our partners, use the IP search engine .

For more information on Intel Cyclone 10 GX FPGAs, visit the Intel Cyclone 10 GX FPGA Overview page .

No 产品名称 Feature 售价(RMB)
1. [C10GFP] Intel® Cyclone® 10 GX FPGA Development Kit
产品编号: T0556  重量: 3,500g
  xxx

标题 版本 档案大小(KB) 新增日期 下载
User Guide   2018-01-05
Schematic   2018-01-05
Kit Collateral (zip)   2018-01-05
